| Specifications |
|---|
| Model | CS-HP7-R110-2W2TFC |
|---|
| Outdoor Doorbell
Parameters |
|---|
| Image Sensor | 1/2.7" Progressive
Scan CMOS (supports low light sensitivity) |
|---|
| Lens | 2.0 mm @ F2.2, view angle:
162° (Diagonal) |
|---|
| Day & Night | IR-cut filter with
auto-switching, 850nm infrared light x 2 (max. 6m) |
|---|
| Max. Resolution | 2K (2048x1296) |
|---|
| DNR | 2D / 3D DNR |
|---|
| Video Compression | H.265 / H.264 |
|---|
| Frame Rate | Max: 15fps; self-adaptive
during network transmission |
|---|
| Outdoor Doorbell
Interface |
|---|
| Audio Input | Built-in high-sensitivity
microphone |
|---|
| Audio Output | Built-in high-power
speaker |
|---|
| Doorbell Button | Supports, 1 button. Can set
the light on or off. |
|---|
| Name Card | Supports, handwritten. 3
cards stickers included (1 sticker already on the intercom panel). |
|---|
| Terminal | Two wiring ports to connect
screen. Two wiring ports to connect gate. Two wiring ports to connect
electric strike plate. |
|---|
| Functions |
|---|
| Intelligent Alarm | Smart human motion
detection; loitering Card |
|---|
| Tamper Alarm | Supports |
|---|
| Video Intercom | Long-distance video two-way
talk |
|---|
| Connection and Function |
|---|
| Connection Method | Wired connection (2-Wired,
capable with 4-Wired), Digital signal transmission |
|---|
| Transmission Distance | Φ 2 x 0.75mm² , max.50m Φ
2 x 1.5mm² , max.100m Twisted pair , max.120m |
|---|
| Open the Door (Gate) | Supports. 2 wiring ports.
1-10m distance. The intercom panel provides a "dry" -contact connection, without an electric current, to connect to the button for automated
gate, gate breaking capacity: 12V/2A |
|---|
| Unlock (Electric Strike
Plate) | Supports. 2 wiring ports.
1-10m distance. The electric strike plate or lock that you order must have a mechanical memory; the power supply to the electric strike plate
or lock must not exceed 12V/1.1A, other wise should do as user
manual. |
|---|
| Door Open Methods | 1.RFID badge unlock (CPU
card × 5 pcs) 2.App remote unlock 3.Indoor display unlock |
|---|
| General |
|---|
| Operation Conditions | -30°C to 60°C , Humidity
95% or less (non-condensing) |
|---|
| Ingress Protection Grade | Waterproof, with shield
cover |
|---|
| Size | 161 × 87 × 20mm (6.34 ×
3.43 × 0.87 inch) |
|---|
| Power Supply | 24V DC from screen |
|---|
| Interior Display |
|---|
| Display Size | 7" touch screen |
|---|
| Resolution | 1024 × 600 |
|---|
| Interface |
|---|
| Audio Input | Built-in high-sensitivity
microphone |
|---|
| Audio Output | Built-in high-power
speaker |
|---|
| Button | Screen on / off button |
|---|
| Terminal | Two wiring ports to connect
1st outdoor doorbell. Two wiring ports to connect 2nd outdoor doorbell. Two wiring ports to connect extra interior screen. (not include the
kit) |
|---|
| SD Card | Supports up to 512GB |
|---|
| Network Parameters |
|---|
| Protocol | EZVIZ Cloud Proprietary
Protocol |
|---|
| Interface Protocol | EZVIZ Cloud Proprietary
Protocol |
|---|
| Protocol | EZVIZ Connect Protocol |
|---|
| Wi-Fi Parameters |
|---|
| Wi-Fi Standard | IEEE802.11b, 802.11g,
802.11n, 802.11ac |
|---|
| Frequency Range | 2.4GHz ~ 2.4835GHz 5.15GHz
~ 5.25GHz |
|---|
| Channel Bandwidth | Supports 20MHz |
|---|
| Security | 64/128-bit
WEP, WPA/WPA2, WPA-PSK/WPA2-PSK |
|---|
| Transmission Rate | 11b: 11Mbps, 11g:
54Mbps, 11n: 150Mbps, 11ac: 433.3Mbps |
|---|
| Function |
|---|
| Multiple ringtones | Up to 20 ringtones |
|---|
| Functions | Live view, Playback,
Two-way talk, Video call |
|---|
| General |
|---|
| Operation Conditions | -10°C to 45°C, Humidity 95%
or less (non-condensing) |
|---|
| Weight | Net weight: 855 g (30.16
oz) |
|---|
| Size | 180 × 111 × 15 mm (7.09 ×
4.37 × 0.59 inch) |
|---|
| Power Supply | DC 24V 1A power supply,
adaptor (100-240Vac) |
|---|
| Power Consumption | 8W, Max. 24W |
|---|
| In the box |
|---|
| in the box | - Monitor |
|---|
| - Wall Bracket for
Monitor |
| - Power Adapter for
Monitor |
| - Drill Template for
Monitor |
| - Intercom Panel (Doorbell)
with a Weather-Proof Shield x 2 |
| - Drill Template for
Intercom Panel x 2 |
| - Screwdriver |
| - Badge x 5 |
| - Screw Kit x 3 |
| - Name Card x 4 |
| -Wires and Wire Connectors
x 2 |
| - DC 24V Power Supply Jack
Connector Cable |
| - Regulatory Information x
2 |
| - Quick Start Guide |
| Certifications |
|---|
| Certifications | CE / REACH / WEEE /
RoHS |
|---|
