H6c G1 3K |H6c G1 4K

H6c G1 3K

Detail

Local storage cards must be purchased separately. Cloud storage service is only available in certain market regions. Please verify availability before making a purchase.
The sales data are collected by EZVIZ from all of its traceable sales channels in the international markets (excluding mainland China) and refer to the total units sold of the H6c family (including the past H6c and H6c models that have an identical appearance)from the period 2022-2024.
The awards shown on this page include all the product design awards that EZVIZ as a company won from 2022 to 2024, and are not honors only for indoor cameras.
Data from EZVIZ Lab's test results under standard conditions. The video compression efficiency will vary with the frequency and complexity of the activity captured, as well as other environmental factors.

H6c G1 3K

Next-Generation Pan & Tilt Wi-Fi Smart Home Indoor Camera

Specifications

Specifications
Specifications	CS-H6c-R200-1Q5WFL
Camera
Image Sensor	1/3" Progressive Scan CMOS
Shutter Speed	Self-adaptive shutter
Lens	4mm@F1.6, view angle: 105°(Diagonal), 88° (Horizontal), 46°(Vertical)
Lens Mount	M12
Day & Night	IR-cut filter with auto-switching
DNR	3D DNR
WDR	WDR
Compression
Video Compression	H.264 / H.265
Video Bit Rate	Adaptive bit rate
Max. Resolution	3K (2880 × 1620）
Frame Rate	Self-adaptive during network transmission
Network
Smart Alarm	Motion Detection, AI-Powered Human Shape Detection
Wi-Fi Pairing	AP pairing
Protocol	EZVIZ Cloud Proprietary Protocol
Interface Protocol	EZVIZ Cloud Proprietary Protocol
Interface
Storage	Supports microSD card (max. 512 GB)
Power	Type-C
Wired Network	RJ45 × 1 (10 M / 100 M self-adaptive Ethernet port)
Wi-Fi
Standard	IEEE802.11a, 802.11b, 802.11g, 802.11n,
Frequency Range	2.4 GHz: 2.4 GHz ~ 2.4835 GHz
Channel Bandwidth	2.4G: Supports 20 MHz
Security	WPA/WPA2, WPA-PSK/WPA2-PSK
Transmission Rate	11b 11Mbps, 11g 54Mbps, 11n MCS7, 11a 54Mbps, 11ac MCS9.11ax MCS11
Output Power (EIRP)	19 dBm
Antenna Gain	1.9 dBi
General
Operating Conditions	-10°C to 45°C (14°F to 113 °F ) Humidity 95% or less (non-condensing)
Power Supply	DC 5V / 2A
Power Consumption	Max. 8 W
IR Range	Max. 10 meters (32.81ft)
Dimensions	88 × 88 × 117.3 mm (3.46 × 3.46 × 4.61 inch)
Packaging Dimensions	103 × 103 × 168 mm (4.06 × 4.06 × 6.61 inch)
Net Weight	222 g (0.49 lb)
In the box
In the box	- H6c G1 Camera
	- Power Adapter
	- Power Cable
	- Drill Template
	- Mounting Plate
	- Screw Kit
	- Regulatory Information × 2
	- Quick Start Guide
Certifications
Certifications	CE / UL / WEEE / REACH / RoHS
